It is an original CPU fan for HP Envy X360 13m-ag series with a part number L23528-001. This fan is compatible with all HP Envy X360 13-AG series laptops.
Features:
1. It is a 100% genuine CPU fan.
2. It is a CPU fan only, without a heatsink.
3. The fan has four wires that connect to the motherboard.
Part Number:
L23528-001
Specifications:
Input: DC5V
Output: 0.5A
Condition: Original, New
Warranty: One (1) Year
Compatible laptop:
Envy X360 13-ag0000au
Envy X360 13-ag0000ne
Envy X360 13-ag0000nf
Envy X360 13-ag0001au
Envy X360 13-ag0001ne
Envy X360 13-ag0001ng
Envy X360 13-ag0002na
Envy X360 13-ag0002ns
Envy X360 13-ag0003au
Envy X360 13-ag0003na
Envy X360 13-ag0004nf
Envy X360 13-ag0004ng
Envy X360 13-ag0004nw
Envy X360 13-ag0004nx
Envy X360 13-ag0005nl
Envy X360 13-ag0006nf
Envy X360 13-ag0006nl
Envy X360 13-ag0007ca
Envy X360 13-ag0009ng
Envy X360 13-ag0010ca
Envy X360 13-ag0011au
Envy X360 13-ag0012au
Envy X360 13-ag0014au
Envy X360 13-ag0015au
Envy X360 13-ag0022au
Envy X360 13-ag0023au
Envy X360 13-ag0034au
Envy X360 13-ag0035au
Envy X360 13-ag0036au
Envy X360 13-ag0301ng
Envy X360 13-ag0302ng
Envy X360 13-ag0304ng
Envy X360 13-ag0500nd
Envy X360 13-ag0502na
Envy X360 13-ag0502sa
Envy X360 13-ag0590nd
Envy X360 13-ag0600ng
Envy X360 13-ag0700ng
Envy X360 13-ag0804no
Envy X360 13-ag0807nz
Envy X360 13-ag0998na
Envy X360 13-ag0999na
Envy X360 13-ag0999nf
Envy X360 13m-ag0001dx
Envy X360 13m-ag0002dx
and all 13-ag series laptops
Tips:
1. To replace the top cover, you need to remove the bottom cover by removing six Phillips screws under the rubber strips and two Torx T5 screws.
2. With the bottom cover removed, disconnect the battery connector from the motherboard.
3. Disconnect the fan cable from the motherboard.
4. loosen the four screws that secure the heat sink and remove three screws that secure the fan to the motherboard.
5. Now, you can remove the fan from the heatsink. Please make sure the part number L23528-001 is on your old fan.
